Wheels
Heavy Duty Industrial Wheels
Heavy-duty industrial wheels are suitable for a load capacity of up to 3,500 daN.
With special wheel brackets, the series 62 industrial wheels are also suitable for heavy-duty applications and suitable for almost any surface. The core of the wheel is made of aluminum and fitted with a "TR-Roll" polyurethane, hardness 75 Shore A, tread. The wheel dampens noise, is smooth and elastic, and the low rolling resistance makes heavy loads easy to move even with small diameter wheels. With special wheel brackets, the wheel is also suitable for mechanical traction up to a speed of 16 km/h. The wheels are resistant to various weather influences, alcohol and glycol. The brackets are available in galvanized steel or powder-coated steel. There are also variants with double wheels between the bracket for extra heavy duty applications.
Contact us for series 62 heavy duty industrial wheels
The series 63 industrial wheels are suitable for heavy-duty applications with special wheel brackets and can be used on a hard and flat surface. The core of the wheel is made of cast iron or forged steel and fitted with a vulkollan® cast, hardness 93 Shore A, tread. The wheel is resistant to various weather influences and is also resistant to alcohol, glycol, mineral oils and greases. It has a low rolling resistance, is relatively insensitive to damage, is wear-resistant and sound-absorbing. With special brackets, the wheel is also suitable for mechanical traction up to a speed of 16 km/h, even with very heavy loads. The brackets are available in galvanized steel or powder-coated steel. There are also variants with double wheels between the bracket for extra heavy duty applications.
Contact us for series 63GH heavy duty wheels
The series 64 industrial wheels with special wheel brackets are suitable for very heavy applications and can be used on a clean, hard and flat surface. The core of the wheel is made of cast iron with a cast "TR" polyurethane, hardness 95 Shore A, tread. The wheel has a low rolling resistance, is relatively insensitive to damage, is wear-resistant and sound-absorbing. It is resistant to weather influences and to alcohol, glycol, mineral fats and oils. With special brackets, the wheel is also suitable for mechanical traction up to a speed of 16 km/h, even with very heavy loads. The brackets are available in galvanized steel or powder-coated steel. There are also variants with double wheels between the bracket for extremely heavy applications.
Order series 64 heavy industrial wheels
The series 65 industrial wheels with special wheel brackets are suitable for very heavy applications and can be used on a clean, flat surface in a dry, or not permanently damp, environment. The core of the wheel is made of cast iron or cast aluminum and fitted with a cast "TR" polyurethane, hardness 95 Shore A, tread. The wheel has a low rolling resistance, is relatively resistant to damage, is elastic, sound-absorbing and wear-resistant. It is suitable for moving medium to very heavy indoor applications, also with mechanical traction up to 6 km/h. Due to the low rolling resistance, this wheel is easy to maneuver even with small wheel diameters.
Order series 65 heavy industrial wheels
The series 66 industrial wheels are suitable for heavy-duty applications and can be used on a relatively flat surface in a dry, or not permanently damp, environment. The core of the wheel is made of polyamide 6 with a molded "TR" polyurethane, hardness 95 Shore A, tread. As a result, the wheel has a low rolling resistance, it is elastic and at the same time wear-resistant. The ball bearing variants are also suitable for manual and automatic traction up to a speed of 6 km/h. Due to the low rolling resistance, the load can be maneuvered with minimal effort. The wheel brackets are available in galvanized steel or stainless steel.
Order series 66 heavy industrial wheels
The series 68 industrial wheels with double wheels and special brackets are suitable for extremely heavy applications up to 1,800 kg load capacity. The wheels are suitable for use on a flat surface in a dry environment. When the wheel is fitted with stainless steel bracket, it can also be used in a damp environment. The wheel is made of white polyamide six with a hardness of 70 Shore D. This gives the wheel a very low rolling resistance, so that minimal force is required for displacement. The wheel is suitable for applications that are usually stationary, but must be able to be moved, for example for cleaning. It is well usable for both indoor and outdoor environments. The wheels have good resistance to weak acids and moderate resistance to strong acids. They are also resistant to water, alcohol, weak bases and hydrocarbons.
Order series 68 heavy industrial wheels
The series 69 industrial wheels are suitable for heavy-duty applications and for use on hard and flat surfaces in a dry environment. The core of the wheel is made of painted cast iron and has a bare cast iron tread. This ensures a very low rolling resistance, so that minimal force is required for displacement. The wheels can be used well in applications that are usually stationary, but still need to be able to be moved, for example for cleaning. The variant with plain bearing can withstand high temperatures of up to 400°C. When the wheels are used in temperatures higher than 100°C, they must be fitted with special brackets that can withstand these temperatures.
Order series 69 heavy industrial wheels
The series 72 industrial wheels are suitable for heavy-duty applications and can be used both indoors and outdoors on almost any flat and non-flat surface. The wheels are suitable for use in a dry, or not permanently damp, environment with temperatures between -20°C and 70°C. The core of the wheel is made of painted cast iron in combination with a hub and two sealed ball bearings. This is provided with a vulcanized "Sigma" elastic rubber, hardness 70 Shore A, tread. This makes the wheel resistant to damage, it is vibration-damping and wear-resistant. They have good resistance to weak acids and alcohol. This series 72 wheels are widely used for cart in an industrial or production environment, both indoors and outdoors, for hand pallet trucks and heavy waste containers.
