Combination bearings and associated -U-profiles

Combination bearings for -U-profile

TypedTDHhBASrC
kN
Co
kN
Ca
kN
Coa
kN
D on
order
for profile
400-0053 (4.0053)304052,5332717515224,834,59,211,7upon requestS/EC053
400-0054 (4.0054)30426237,530,5202,52033965,214,42162,52890
400-0055 (4.0055)354870,14436232,522455,591,717,62570,4/70,72867
400-0056 (4.0056)405377,74836,523324458,410023,235,878,1/78,52810
400-0058 (4.0058)455988,45744303,526383,8132,327,74288,92811
400-0061 (4.0061)6071107,7695531435594,2160,738,665,2108,2/108,52862
400-0062 (4.0062)608012372,356375405128226,85392upon request2891
400-0063 (4.0063)6010814978,558,5455,5503172,3325,9133,3

244

upon request2757
400-0011 (4.0011)601081498667455,5503172,3325,9133,3244upon request2757
400-0037 (4.0037)801201749571557637265488205,3381upon requestupon request
400-0039 (4.0039)801201859571557637265488205,3381upon requestupon request
  • C = dynamic carrier number
  • Co = static carrier number
  • Ca = axial dynamic load number
  • Coa = axial static load rating
  • Weldable shaft journal made of steel St52 - tolerance -0.05mm

Order combination bearings

Adjustable combination bearings for -U- profile

TypedTDHhBASrC
kN
Co
kN
Ca
kN
Coa
kN
D on
order
for profile
400-0072 (4.0072)3042624333205,51633965,25,8662,52890
400-0073 (4.0073)354870,14840236,516455,591,75,8670,4/70,72867
400-0074 (4.0074)405377,75139,523721458,410013,214,578,1/78,52810
400-0076 (4.0076)455988,4614830721383,8132,313,214,588,92811
400-0078/L (4.0078/L)6071107,7735931833594,2160,72528108,2/108,52862
400-0079 (4.0079)608012375,859,5378335128226,82528upon request2891
400-0080 (4.0080)6010314989694515505172,3325,983130upon request2757
  • C = dynamic carrier number
  • Co = static carrier number
  • Ca = axial dynamic load number
  • Coa = axial static load rating
  • Weldable shaft journal made of steel St52 - tolerance -0.05mm

Order combination bearings

Adjustable combination bearings for -U- profile

TypedTDHh minh maxBASrC
kN
Co
kN
Ca
kN
Coa
kN
for profile
400-0454 (4.0454)30426237,530,5322042033965,216252890
400-0455 (4.0455)354870,1443637,5234204

55,5

91,716252867
400-0456 (4.0456)405477,7483738,5233,526458,410023362867
400-0458 (4.0458)455988,4574445,530426483,8132,323362811
400-0461 (4.0461)6069107,769555731430594,2160,732502862
400-0462 (4.0462)608012372,35660374,5345128226,841722891
400-0463 (4.0463)6010814978,558,562,5456343172,3325,941722757
  • C = dynamic carrier number
  • Co = static carrier number
  • Ca = axial dynamic load number
  • Coa = axial static load rating
  • Weldable shaft journal made of steel St52 - tolerance -0.05mm

Order combination bearings

-U-profiles hot rolled structural steel

Type(b)b1Tol.b2Tol.hTol.h1Tol.cdr1r2r3wt. in
kg per meter
Wx
cm3
S/EC053656±0,553±0,430±0,56±0,544≤64-5,311,9
289086,512±0,562,5+136±0,87±0,5153≤62-3410,532
2867103,216,2±0,570,8±0,540±0,87,7±0,5153≤62-3514,853
2810121,321,3±0,578,7±0,541±0,810,8±0,5155≤62-3520,981
2811135,423±0,589,4±0,553±0,812,7±0,5155≤62-3528,6128
2862157,224,4±0,5108,4±0,561,2±0,814±0,5155≤62-3535,9190
289117525,6±0,5123,8±0,566,2±0,816,2±0,5155≤62-3542,9250
2757201,525,7±0,5150,1±0,571,2±0,819,4±0,5205≤82-3652,3340
  • Profiles can be supplied in any desired length up to a maximum of 12 meters
  • Do not paint, coat, etc. on the inside profiles
